Delta VFD002EL21A 0.2kW (0.25HP) VFD – 230V Single Phase Input, 3 Phase Output, 1.6A
VFD & Drives
2 / 2

VFD & Drives

Delta VFD002EL21A 0.2kW (0.25HP) VFD – 230V Single Phase Input, 3 Phase Output, 1.6A

Brand: DELTAModel: VFD002EL21A

Technical Specifications

Brand
Delta
Depth
136
Model
VFD002EL21A
Width
72
Height
174
Series
VFD-EL
Mounting
Panel Mount / DIN Rail
Drive Type
Micro AC Drive
Frame Size
A
RFI Switch
true
Closed Loop
false
Input Phase
1
Output Phase
3
Product Type
Variable Frequency Drive
Input Voltage
200-240 VAC
Control Method
V/F (V/Hz) Control
Cooling Method
Natural Cooling
Dimension Unit
mm
Motor Quantity
1
Built-in Keypad
true
Dynamic Braking
true
Input Frequency
50/60 Hz
Overload Capacity
150% of rated current for 1 minute
Protection Rating
IP20
Built-in EMI Filter
true
DC Injection Braking
true
PID Feedback Control
true
RS-485 Communication
true
Rated Output Current
1.6
Operating Temperature
-10 to 50 °C
Applicable Motor Power
0.2 kW
Communication Protocol
Modbus
Regenerative Operation
false
Maximum Output Frequency
600
Minimum Output Frequency
0.1
Applicable Motor Power HP
0.25
Dynamic Braking Transistor
true
☆☆☆☆☆
No reviews yet
$450.00

Product Description

Scroll to read

Product Description The Delta VFD002EL21A is a compact VFD-EL Series variable frequency drive designed for speed control and operation of small three-phase AC motors. It is rated for 0.2 kW (0.25 HP) motors and accepts a single-phase 200–240 VAC input, providing a three-phase output with a rated current of 1.6 A. - Delta The VFD002EL21A features V/F (V/Hz) control, a built-in keypad, RS-485 communication with Modbus, built-in EMI filtering, overload protection, and a built-in dynamic braking transistor. The drive supports an output frequency range of 0.1–600 Hz, making it suitable for a wide range of small machine and automation applications. DeltaACDrives.com Its compact Frame A construction measures approximately 72 × 174 × 136 mm, making it suitable for space-constrained control panels.
